Product Information "Regenerative DC Electronic Load | IT-M3300 Series"
ITECH IT-M3300 Series
Regenerative, Electronic DC Load with Simulation of Various Load Characteristics, Form Factor half 19 inch, 1U, Parallel Connection of up to 16 Units
Power: up to 800 W, Voltage: up to 600 V, Current: up to 30 A, 1/2 19'' & 1 U
IT-M3300 regenerative DC electronic load can not only simulate various load characteristics, but also can feed back electrical energy to the local grid instead of heat. With high power density design, it can provide up to 800W power absorption with tiny body of only 1U half-rack. Its flexible modular architecture design can meet the test requirement of customers with different current and power. At the same time, it has high-precision output and measurement, and has made a number of safety designs for the test. It is suitable for test applications such as various types of battery discharge, multi-channel power supply, and semiconductor aging.
Related links to "Regenerative DC Electronic Load | IT-M3300 Series"
Available documents (Subject to change)
Specifications of the Regenerative DC Electronic Load - IT-M3300 Series
- Power: 0 - 800 W
- Voltage: 0 - 600 V
- Current: 0 - 30 A
- Size: 1/2 1 U
- High power density up to 800 W in 1 U 1/2 rack
- Parallel connection of up to 16 units
- High efficient power regeneration
- Optional interfaces: GPIB/analog & RS232 / USB / CAN / LAN / Analog / Digital IO / RS485
- Various protection functions: OCP. UCP. O VP. U VP. OPP. Precharge function to prevent overshoot of DC loading current
- 8 operating modes: CC, CV, CP, CR, CV+CC, CC+CC, CV+CR, CV+CR, CV+CC+CP+CR
- Current rise / fall time adjustable
- 5 optional interfaces available: RS232, CAN, Ethernet/LAN, GPIB/IEEE488, USB_TMC, USB_VCP, RS485, Analog- and IO-communication
- Precharge function to prevent overshoot of DC loading current
- High-speed measurement, keep 10 times / s update rate even connecting 16 stand-alone
- List programming
Application of the Regenerative DC Electronic Load - IT-M3300 Series
- Laboratories
- Test stands
- Battery discharge
- Multi-channel powel supplies
- Semiconductor aging
